Autodesk® Robot Structural Analysis Professional (Robot™) is a structural analysis and design software application. Use it to analyze any type and shape of a structure, as well as to design elements of the structure (steel, concrete, and wood elements).
The algorithms implemented in Robot allow the analysis of the geometry of a structure model defined in Revit. It also allows the advanced creation of meshes of flat elements (plates, walls and covers) included in the model. The following structures can be analyzed:
- Curved walls and floors/panels on any plane
- Bracing cores and walls
- Walls and floors with openings of any shape
- Mixed-Material Models
Using Robot's complex modeling and analysis features, Revit users can directly analyze their models.
